Engine

No. cylinder

4 flat

CC (x1.7 if turbocharged)

1994 (3390)

Bore / Stroke (mm)

92 / 75

Comp. Ratio

8,8:1

Max.Power (bhp)

300

Revs.

6500

Max.Torque (kg/m)

47

Revs.

4000

Induction

Subaru Inj.

Turbo

IHI

No. Valves

16

No. + Position Cams

2 x 2 Overhead Camshaft

Location

Front-Longitudinal

Transmission

Location

4WD

Differential (Front-Central-Rear)

Active-Active-Mechanical

Clutch (Manufacturer)

Carbon (AP) 3 plate

Gearbox (Manufacturer)

6 speed (Prodrive)

Brakes

Front / gravel

DV304

Front / asphalt

DV355

Rear / gravel

DV304

Rear / asphalt

DV355

Suspension (shock absorbers)

Front

McPherson (Bilstein)

Rear

McPherson (Bilstein)

Dimensions

Length (mm)

4340

Widht (mm)

1690

Height (mm)

1405

Wheelbase (mm)

2520

Front track (mm)

1465

Rear track (mm)

1465

Weight (kg)

1230

Date 1st Homologation (number)

1.4.1993 (A5480)

1st Major Rally

Finland 1993

WRC Wins (11)

Greece 1994 (Sainz)

New Zealand 1994 (McRae)

RAC 1994 (McRae)

Monta Carlo 1995 (Sainz)

Portugal 1995 (Sainz)

New Zealand 1995 (McRae)

Spain 1995 (Sainz)

RAC 1995 (McRae)

Greece 1996 (McRae)

Italy 1996 (McRae)

Spain 1996 (McRae)
