Engine |
|
No.
cylinder |
4
flat |
CC
(x1.7 if turbocharged) |
1994
(3390) |
Bore
/ Stroke (mm) |
92
/ 75 |
Comp.
Ratio |
8,8:1 |
Max.Power
(bhp) |
300 |
Revs. |
6500 |
Max.Torque
(kg/m) |
47 |
Revs. |
5000 |
Induction |
Subaru
Inj. |
Turbo |
IHI |
No.
Valves |
16 |
No.
+ Position Cams |
2
x 2 Overhead Camshaft |
Location |
Front-Longitudinal |
Transmission |
|
Location |
4WD |
Differential
(Front-Central-Rear) |
Mechanical-Hydraulic-Mechanical |
Clutch
(Manufacturer) |
Carbon
1 plate |
Gearbox
(Manufacturer) |
6
speed (Prodrive) |
Brakes |
|
Front
/ gravel |
DV304 |
Front
/ asphalt |
DV355 |
Rear
/ gravel |
DV304 |
Rear
/ asphalt |
DV332 |
Suspension
(shock absorbers) |
|
Front
|
McPherson
|
Rear |
McPherson
|
Dimensions |
|
Length
(mm) |
4510 |
Widht
(mm) |
1705 |
Height
(mm) |
1420 |
Wheelbase
(mm) |
2580 |
Front
track (mm) |
1465 |
Rear
track (mm) |
1455 |
Weight
(kg) |
1208 |
Date
1st Homologation (number) |
1.1.1990
(A5399) |
1st
Major Rally |
Kenya
1990 |
WRC
Wins (1) |
New
Zealand 1993 (McRae) |
|
|
