Engine

No. cylinder

4 in line

CC (x1.4 if turbocharged)

1759 (2462)

Bore / Stroke (mm)

88.5 / 71.5

Comp. Ratio

7,0:1

Max.Power (bhp)

450

Revs.

8000

Max.Torque (kg/m)

46

Revs.

5000

Induction

Weber-Magneti Marelli

Turbo

KKK+Roots compressor

No. Valves

16

No. + Position Cams

2 Overhead Camshaft

Location

Mid-Longitudinal

Transmission

Location

4WD

Differential (Front-Central-Rear)

Clutch (Manufacturer)

2 plate

Gearbox (Manufacturer)

5 speed

Brakes

Front

DV300

Rear

DV300

Suspension (shock absorbers)

Front

Wishbone+Coil

Rear

Wishbone+Coil

Dimensions

Length (mm)

3990

Widht (mm)

1880

Height (mm)

1360

Wheelbase (mm)

2440

Front track (mm)

1510

Rear track (mm)

1535

Weight (kg)

890

Date 1st Homologation (number)

1.11.1985 (B276)

1st Major Rally

1000 Pistes 1985

1st WRC Event

RAC 1985

WRC Wins (5)

RAC 1985 (Toivonen)

Monte Carlo 1986 (Toivonen)

Argentina 1986 (Biasion)

Italy 1986 (Alen)

USA 1986 (Alen)
