Engine |
|
No.
cylinder |
4
in line |
CC
(x1.7 if turbocharged) |
1998 |
Bore
/ Stroke (mm) |
86
/ 86 |
Comp.
Ratio |
11,0:1 |
Max.Power
(bhp) |
230 |
Revs. |
7500 |
Max.Torque
(kg/m) |
24 |
Revs. |
5250 |
Induction |
MBE
Inj. |
Turbo |
no
turbo |
No.
Valves |
16 |
No.
+ Position Cams |
2
Overhead Camshaft |
Location |
Front-Transverse |
Transmission |
|
Location |
Front-wheel
drive |
Differential
(Front-Central-Rear) |
Viscous
|
Clutch |
Ceramic
1 plate |
Gearbox
|
6
speed (MNE-FFD) |
Brakes |
|
Front
/ gravel |
DV305 |
Front
/ asphalt |
DV332 |
Rear
/ gravel |
DV280 |
Rear
/ asphalt |
DV280 |
Suspension
(shock absorbers) |
|
Front
|
McPherson
(Bilstein) |
Rear |
Parallel
Link Strut (Bilstein) |
Dimensions |
|
Length
(mm) |
3975 |
Widht
(mm) |
1690 |
Height
(mm) |
1410 |
Wheelbase
(mm) |
2430 |
Front
track (mm) |
1435 |
Rear
track (mm) |
1415 |
Weight
(kg) |
950 |
Date
1st Homologation (number) |
1.1.1993
(A5470) |
1st
Major Rally |
RAC
1993 |
|
|
