Engine |
|
No.
cylinder |
4
in line |
CC
(x1.7 if turbocharged) |
1999
(3398) |
Bore
/ Stroke (mm) |
82.5
/ 93.5 |
Comp.
Ratio |
9.5:1 |
Max.Power
(bhp) |
298 |
Revs. |
5500 |
Max.Torque
(kg/m) |
52 |
Revs. |
4000 |
Induction |
EFI |
Turbo |
Garrett |
No.
Valves |
20 |
No.
+ Position Cams |
2
Overhead Camshaft |
Location |
Front-Transverse |
Transmission |
|
Location |
4WD |
Differential
(Front-Central-Rear) |
Active-Active-Mechanical |
Clutch
(Manufacturer) |
Carbon
(Alcon) 3 plate |
Gearbox
(Manufacturer) |
6
speed sequential (Skoda) |
Brakes |
|
Front
/ gravel |
DV304 |
Front
/ asphalt |
DV378 |
Rear
/ gravel |
DV304 |
Rear
/ asphalt |
DV366 |
Suspension
(shock absorbers) |
|
Front
|
MacPherson
(Proflex) |
Rear |
MacPherson
(Proflex) |
Dimensions |
|
Length
(mm) |
4511 |
Widht
(mm) |
1770 |
Height
(mm) |
1429 |
Wheelbase
(mm) |
2512 |
Front
track (mm) |
1585 |
Rear
track (mm) |
1585 |
Weight
(kg) |
1240 |
Date
1st Homologation |
1.1.1999 |
1st
Major Rally |
Monte
Carlo 1999 |
Debut:
Octavia WRC EVo 2 |
Cyprus
2000 |
Debut:
Octavia WRC Evo 3 |
Finland
2002 |
Best
WRC Result |
3rd
Kenya 2001 (Schwarz) |
|
|
